Многопортовый маршрутизатор RSM100-LAN | Delta Logic

от имеет Комментарии к записи Многопортовый маршрутизатор RSM100-LAN | Delta Logic отключены
Ноябрь 15, 2018

21 220,00

* цена товара указана без НДС
** цена может изменяться в зависимости от курса НБУ на дату выставления счета

Многопортовый маршрутизатор для интеллектуальных сетевых сетей стандартных станков с ЧПУ

Производитель стандартных станков с ЧПУ может избежать использования многопортового маршрутизатора RSM100-LAN, возможно, с ошибкой настройки конфигурации сети. Роутер выступает посредником между сетями компаний, предприятий и сервисов. Идеально подходит для машин с Siemens SINUMERIK 840D sl. Они могут быть достигнуты и настроены в шагах fes со стандартными настройками IP ПЛК из сети компании. После простой и уникальной конфигурации маршрутизатора машинам присваивается уникальный идентификатор. Они уже могут быть определены клиентом. Другие детали завода не должны быть настроены.

Артикул: RSM100-LAN Категория:

Описание

Product highlights
  • LAN-to-LAN router with 8-multi-port switch (3x WAN, 5x local)
  • Ideal for machines and systems with SINUMERIK 840D sl
  • Easy configuration with IP standard settings
  • Comfortable access to the individual components of the control
  • Highest possible security at WAN and local interfaces due to VPN, firewall, etc.
  • Quick start for INSYS Connectivity Service VPN service
Product information “Multiport router RSM100-LAN”

Multiport router for intelligent netwerk integration of CNC standard machines

Manufacturer of CNC standard machines can avoid with the multiport router RSM100-LAN the possibly error-prone adjustment of the network configuration. The router mediates between the company, plant and service networks. Its ideal for machines with the Siemens SINUMERIK 840D sl. These can be reached and configured in a fes steps with the standard IP settings of the PLC from the company network. The machines are assigned a unique identifier after simple and unique configuration of the router. These can already be defined by the customer. The other plant parts do not have to be configured.

Varied fields of application

The RSM100-LAN is suitable for a wide range of applications. Serial machines can be intergated in the network. The network can be segmented into different areas. In addition, the RSM100-LAN enables remote industrial maintenance.

Technical Details

External network (company network)

3 x RJ45 (company network), 10/100 Mbps, full/half duplex, automatic speed adjustment;
MDI/MDI-X, DHCP client, static IP, PPPoE for ADSL modem

Internal network (system network)

5 x RJ45 (system network), 10/100 Mbps, full/half duplex operation, automatic speed
adjustment; MDI/MDI-X, port mirroring, devices of the system network are accessible in the
company network

Router

Function

Full NAT (port forwarding, netmapping), IP forwarding, DNS relay, dynDNS support, DHCP
server, SNMP, NTP client and server, buffered real-time clock

Security OpenVPN (client and server), IPsec, GRE, PPTP, MAC firewall, link loss detection, failed login detection, GRE
Redundancy 2 OpenVPN server targets
Configuration Web interface local and remote, text and binary file, automatic updates
LED 2 LEDs each for indication of network membership and link condition,
4 LEDs for indication of normal operating states of the router
Messages E-Mail, SNMP traps
Additional features
Update of firmware and configuration (local and remote), hardware watchdog
Quick start for DELTA LOGIC Connectivity Service
Physical features
Power supply 12 … 24 V DC (-10%/+20%) via screw terminal
Power consumption Approx. 3.5 W
Dimensions (LxWxH) 55 mm x 110 mmm x 75 mm
Operating temperature -20 °C … +55 °C
Humidity 0 … 95% (non-condensing)
